Description
Features:
* The flat collector is installed on the roof and the tank is installed anywhere separately
* Stylish streamline design, easy installation
* Direct circulating system with higher performance
* Reliable electric back-up with protection against dry heating and thermal cut-out
* Easy operation and intelligent control
* With 5STAR quality flat solar collector and enamel water tank for long service life
* Polyurethane insulation with good heat reservation
* Totally metal flow channels made by copper
* Low failure rate and easy maintenance
|
Model No. |
FS-PSN-200 |
FS-PSN-300 |
FS-PSN-400 |
FS-PSN-500 |
|
|
Water Tank |
Circulation type |
Pressurized open loop |
|||
|
Tank capacity |
200L |
300L |
400L |
500L |
|
|
Electric booster |
1.5KW |
2.5KW |
2.5KW |
2.5KW |
|
|
Outer tank material |
Prepainted galvanized steel |
||||
|
Inner tank material |
Low carbon steel with vitreous enamel |
||||
|
Max working pressure |
0.7Mpa |
||||
|
Insulation material |
Polyurethane |
||||
|
Solar Collector |
Overall area |
2㎡*2pcs |
2㎡*2pcs |
2㎡*3pcs |
2㎡*4pcs |
|
Collector dimenrions |
2000*1000*95mm |
2000*1000*95mm |
2000*1000*95mm |
2000*1000*95mm |
|
|
Absorber material |
Full aluminum plate |
||||
|
Absorber coating |
Blue selective coating or Black chrome coating |
||||
|
Welding way |
Laser welding |
||||
|
Hydraulic kit |
Thermometer |
0~200℃ |
|||
|
Water Pump |
Max. discharge flow:3.3 m3/h , Max. pump discharge : 6 m |
||||
|
Flow meter |
2~8L/min. |
||||
|
Controller |
Control circulation pump and electric booster |
||||
|
T/P valve |
0.7Mpa/95℃ |
||||
|
Mounting Bracket |
Auminum alloy |
||||
|
Weight of overall system (empty) [kg] |
174 |
198 |
265 |
319 |
|
